Extech PRC30 Process Calibrator

• Measures:
  • Current, max load, voltage, mV/temp
  • Type J, K, T, E, C, R, S, N thermocouple types
• ±(0.01% + 1 digit) or ±(0.05% + 1.8°F or 1°C) accuracy
• 24V Loop Power
• Zero adjustment, auto zero when power on and change mode
• Standard banana I/O ports
• Large battery bank for extended work cycle
• External power adapter for continuous work cycle

The Extech PRC30 Process Calibrator provides a high accuracy calibration function that simulates precision thermocouple
outputs for use in calibrating thermometers, transmitters, controllers or recorders. The palm sized unit has double molded
housing and a large dot-matrix backlit LCD display. The PRC30 has up to five user adjustable calibration presets and measures
DC process signals.

Applications for the Extech PRC30 Process Calibrator include:

• Lab and Field Calibration and Verification Operations of Sensors, Thermocouple Probes, Controllers, Panel meters & Testing tools.
• Temperature Control Process Troubleshooting
• Process devices calibration and simulation: Transducers, Transmitters, Indicators, Controllers, and Recorders
• Field test and service
• Bench research and development

The Extech PRC30 Process Calibrator ships complete with:

• Test leads
• Alligator clips
• Thermocouple calibration cable with subminiature connector
• Universal calibration cable with subminiature terminal
• 100V-240V AC Universal Adaptor with 4 plugs
• Six 1.5V AA batteries
• Hard carrying case
