Fluke 83V Industrial Multimeter

• DC volts
  • Range: 600.0 mV, 6.000 V, 60.00 V, 600.0 V, 1000 V
  • Accuracy: 0.1%
• AC volts
  • Range: 600.0 mV, 6.000 V, 60.00 V, 600.0 V, 1000 V
  • Accuracy: 0.5%
• DC current
  • Range: 600.0 µA, 6000 µA, 60.00 mA, 600.0 mA, 6.000 A, 10.00 A
  • Accuracy: 0.4%
• AC current
  • Range: 600.0 µA, 6000 µA, 60.00 mA, 600.0 mA, 6.000 A, 10.00 A
  • Accuracy: 1.2%
• 6000 count, 3-3/4 digit display
• Resistance, continuity and diode test
• Min/Max-Average recording with Min/Max Alert to capture variations automatically
• Auto and manual ranging for maximum flexibility
• Analog bargraph for fast changing or unstable signals
• Input Alert provides audible warning against wrong use of input jacks

The Fluke 83V is the base model of the Fluke 80 Series V Industrial Multimeters offering a solid meter
for basic, accurate digital multimeter usage. The 80 Series V operates much like the classic 80
series, but with more problem solving power, safety, convenience and impact protection.

The large digit display with bright, two-level backlight makes the 80 series V significantly easier to
read than older models. The 83V has auto and manual ranging modes for maximum flexibility. The 83V
has an analog bargraph, resistance, continuity and diode test, and measures frequency to 200 kHz and
% duty cycle.

The Fluke 83V has a relative mode to remove test lead resistance from low ohm measurements and an
improved sleep mode for long battery life. All inputs are protected to Category III, 1000V and Category
IV 600 V. They can withstand impulses in excess of 8,000 V and reduce risks related to surges and spikes.

The Fluke 83V meter ships complete with:

• TL75 test leads
• AC72 alligator clips
• Holster
• 9V battery
• CD-ROM user’s manual
• Operator’s guide
