INOR LCD-H11X Loop Powered Field Indicator

• Can be used with any DIN B transmitter or as display only
• Installation directly in a 4-20 mA loop without need for power supply
• Only 1.5 V voltage drop
• High-contrast, 4-digit LCD display
• Simple push button scaling without reference signal
• Any range between -1999 to 9999 for 4 to 20 mA input
• Labels for different engineering units are included
• Typical accuracy of 0.05 % allows for high precision read-outs

The INOR LCD-H11X is a digital, heavy-duty LCD indicator for installation directly in a 4-20 mA loop without need for external power.

The indicator is equipped with high-contrast, easy-to-read LCD digits. The scale is easily programmable, without reference signal,
by three push buttons for any values between – 1999 and 9999.

Additional features:

• HART transparent
• Designed for ambient temperatures between -25 to +70 °C / -13 to +158 °F
• Field mounting in rugged IP 66 / NEMA 4X housing
• 90° indexing of display orientation
